As the name suggests, Mini-Bar memory tokens and receptacles are miniaturized versions of the Datakey Bar series of products. Mini-Bar receptacle models are more than 60 percent smaller than the equivalent Bar receptacle models and are offered in two versions. The MBRHN model features an 8-pin header connector and measures 0.64” x 0.58” x 0.53” (16.3mm x 14.7mm x 13.6mm). The MBRFN model measures 0.64” x 0.58” x 0.36” (16.3mm x 14.7mm x 9.1mm) and uses a special interface board with an FFC/FPC connector. The receptacles are available with or without an adhesive gasket and achieve an IP67 seal when properly mounted.

Mini-Bar memory tokens are slightly larger than a microSD card but are thicker, stronger and easier to handle. Currently, there are four memory token models available—all use serial EEPROM. Memory capacity options include 16 Kbits or 256 Kbits with either an SPI or I2C serial interface. In 2025, additional Mini-Bar memory tokens will be introduced featuring Microchip’s CryptoAuthentication™ secure memory ICs.

“Datakey Bar memory tokens and receptacles were released in 2009 and have become a popular choice for credentials in cryptographic products in the United States and Europe,” said Paul Plitzuweit, senior product manager for the Datakey line. “The trend for these cryptographic products, and for many embedded systems, has been toward decreasing sizes over time. The Mini-Bar system aims to strike the perfect balance by reducing the size of the receptacle as much as possible while ensuring that the ‘key’ (or credential) is still easy to handle.”

Customers in North America can purchase Datakey Mini-Bar memory tokens and receptacles and get more information by contacting ATEK Access Technologies (https://datakey.com/). In Europe, the products are available through authorized distributors Nexus Industrial Memory (https://nexusindustrialmemory.com/) and Milexia (https://milexia.com/).

A Mini-Bar memory token inserts into a Mini-Bar receptacle, sliding over its seven spring-probe contacts.

Shown next to a quarter and Euro for scale, the Mini-Bar receptacle is just over five-eighths of an inch or 16mm in length, making it an ideal choice for mobile and hand-held embedded applications.

The Mini-Bar receptacle can be mounted in a corner of a device, minimizing the required front panel space and internal volume. An RJ-45 ethernet jack is shown for size comparison.

About ATEK Access Technologies
ATEK Access Technologies (ATEK) designs and manufactures standard and customized sensing, safety, and portable memory solutions with a focus on quality, ruggedness and long product life cycles. Its brands include Larco and Datakey. ATEK’s Larco product line offers high-quality automatic door products and industrial safety mats, all manufactured in our U.S. facility in Central Minnesota. For more information, visit https://larco.com.

ATEK’s Datakey product line features portable memory devices that utilize solid over-molded construction, industrial-temperature electronics, redundant electrical contacts and high cycle-life receptacles for harsh environments. Datakey products also offer a proven history of long-term availability. Since 1976, Datakey has been the preferred portable memory solution for many of the world’s largest defense, medical, and industrial OEMs. For more information, visit https://datakey.com.
